dB Technologies DVA K5

Technical Data

Speaker Type

3-Way Active Line Array Module

Acoustical data

Frequency Response [+/- 3dB]

70 - 19,000 Hz

Max SPL

One Unit: 129 dB

HF

2x1 "

Voice Coil HF

1.4 "

MF

1x 6.5 "

Type MF

Neodymium

Voice Coil MF

2 "

LF

1x8 "

Voice Coil LF

2.5 "

Type LF

Neodymium

Directivity (HxV)

100x15° Single unit

Amplifier

Amp Technology

Digipro® G3

Amp Class

Class D

RMS Power

500 W

Peak Power

1000 W

Cooling

Convection

Power Supply

500 W SMPS with Auto Range PSU

Processor

Controller

DSP 56 Bit

AD/DA Converter

24 bit/48 KHz

Limiter

Dual Active Multiband RMS, Peak, Thermal

Crossover Frequency MF-HF

1800 Hz

Slope MF-HF

24 dB/Octave

Crossover Frequencies LF-MF

340 Hz

Slope LF-MF

24 dB/Octave

Input

Signal Input

1x XLR Balanced

Signal Output

1x XLR Balanced

Power Socket

1x PowerCON In
1x PowerCON Out

Controls

1 x Input Sensitivity Rotary Switch
1 x DSP Rotary Encoder (LF Correction)
1 x DSP Rotary Encoder (MF-HF Correction)

Mechanics

Housing

Polypropylene PP metal reinforced

Rigging Points

Integrated rigging hardware

Width

580 mm (22.83 in)

Height

240 mm (9.44 in)

Depth

327 mm (12.87 in)

Weight

14.2 kg (31.3 lbs)

Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
