AW-3 Dynamic Wah

Description

UNBELIEVABLE “TALKING” WAH EFFECTS!

The BOSS AW-3 Dynamic Wah pedal gives guitarists a wide range of classic auto-wah and dynamic wah effects, plus a new "Humanizer" effect which can simulate human vowel sounds. A Bass input provides a variety of funky wah sounds for bass guitar.

SPECIFICATIONS

Nominal Input Level                                       -20 dBu

Input Impedance                                            1 M ohms

Nominal Output Level                                    -20 dBu

Output Impedance                                         1 k ohms

Recommended Load Impedance                  10 k ohms or greater

Residual Noise Level                                     -92 dBu (IHF-A, Typ.)

Connectors                                                    GUITAR IN Jack, BASS IN Jack, OUTPUT Jack, EXP/CTL Jack, AC Adaptor Jack (DC 9 V)

Power Supply                                                 DC 9 V: Dry Battery 9 V type (6F22/9 V), AC Adaptor

Current Draw                                                  50 mA (DC 9 V)

Accessories                                                    Dry Battery 9 V type (6F22/9 V)

Options                                                           AC Adaptor (PSA-Series), Expression Pedal (Roland EV-5), Footswitch (FS-5U)

SIZE AND WEIGHT ( INCL. BATTERY )

Width                                                              73 mm
                                                                        2-7/8 inches

Depth                                                              129 mm
                                                                        5-1/8 inches

Height                                                              59 mm
                                                                        2-3/8 inches

Weight                                                              420 g
                                                                         0 lbs. 15 oz.

From the manufacturer

AW-3 Dynamic Wah

UNBELIEVABLE “TALKING” WAH EFFECTS!

The BOSS AW-3 Dynamic Wah pedal gives guitarists a wide range of classic auto-wah and dynamic wah effects, plus a new "Humanizer" effect which can simulate human vowel sounds. A Bass input provides a variety of funky wah sounds for bass guitar.

A “Talking” Pedal

The AW-3 Dynamic Wah is the first compact wah pedal to incorporate human voice-type sounds through a new “Humanizer” Mode. Of course, you can also choose from standard up-and-down wah effects, plus a Tempo Mode and resonant synth-like Sharp Mode.

Endless Possibilities

Choose from both fixed and auto wah settings using the Manual control or pedal for tempo input. By connecting an optional expression pedal, the AW-3 can also be used for Pedal Wah effects. A dedicated Bass input permits direct processing of bass guitars.

• Compact pedal creates a variety of classic "wah" effects
• Dynamic wah sounds provide variable effect based on picking strength
• "Humanizer" effect creates human voice-type vowel sounds
• Dedicated Bass input for processing bass guitar
• EXP Pedal mode allows wah control via optional expression pedal
• Tempo can be set for pedal control or at fixed rate via Manual mode
