310HT UHF Diversity Wireless Microphone System
Inclusive of all GST
310UDR Receiver
Freq. Range: UHF 188 Frequencies (566.125-589.875MHz)
Type of Reception: FM
Oscillator: PLL Synthesized
RF Squelch Level: -95dBm
Frequency Response: 50Hz – 15kHz
S/N Ratio: >84dB 100% Dev.
Output Impedance: 1k Ohms
Audio Out: MIC Level – Balanced – 3.5mm Mini-Jack
-28 dBm – 100% deviation
Batteries: 2 “AA” Alkaline (2 x 1.5V) – 5-6 hours runtime
2 “AA” rechargeable Ni-MH (2 x 1.2V)
Dimen.: 2.48″W x 3.86″H x 1.12″D (63 x 98 x 28.5 mm)
Weight: Approx. 6.7oz (190g) w/batteries
35HT Transmitter
Freq. Range: UHF 188 Selectable (566.125-589.875MHz)
Oscillator: PLL Synthesized
RF Power: 25mW
Frequency Response: 50Hz – 15kHz
Max. Deviation: ±40kHz @ 1kHz Modulation, MIC Input – 65dBm (dev ±5kHz)
Batteries: 2 “AA” Alkaline (2 x 1.5V) – 6-8 hours runtime
2 “AA” rechargeable Ni-MH (2 x 1.2V)
Dimensions: Φ1.89″ x 9.2″L (48 x 234.5 mm)
Weight Approx. 9.5oz (270g) w/batteries
